Product model selection

• Product	Product model	Dot pitch(pixels)	Box dimensions(mm)	Box resolution	Maximum Power Consumption(W)	Average power consumption(W)	Box weight(kg)
  RM Series	RM1.5	1.56	500x500	320x320	190	95	8.2
  	RM1.9	1.95	500x500	256x256	150	55	8.2
  	RM2.3	2.31	500x500	216x216	167	52	8.2

• Product	Product model	Dot pitch(pixels)	Box dimensions(mm)	Box resolution	Maximum Power Consumption(W)	Average power consumption(W)	Box weight(kg)
  RMxC Series	RM1.5C	1.56	500x500	320x320	175	55	9

• Product	Product model	Dot pitch(pixels)	Box dimensions(mm)	Box resolution	Maximum Power Consumption(W)	Average power consumption(W)	Box weight(kg)
  DL Series	DL1.9	1.95	500x500	256x256	125	50	7.2
  	DL2.3	2.31	500x500	216x216	150	60	7.2
  	DL2.6	2.604	500x500	192x192	160	60	7.2

• Product	Product model	Dot pitch(pixels)	Box dimensions(mm)	Box resolution	Maximum Power Consumption(W)	Average power consumption(W)	Box weight(kg)
  SW (RGBW) Series	SW5.7C	5.76	600x1200	104x208	300	98	14.8

• Product	Product model	Dot pitch(pixels)	Box dimensions(mm)	Box resolution	Maximum Power Consumption(W)	Average power consumption(W)	Box weight(kg)
  AE Series	AE1.5E	1.56	500x500	320x320	130	50	12.5
  	AE2.3	2.31	500x500	216x216	88	44	12.5

• Product	Product model	Dot pitch(pixels)	Box dimensions(mm)	Box resolution	Maximum Power Consumption(W)	Average power consumption(W)	Box weight(kg)
  CV MIP Series	CVMS0.9	0.9375	600x337.5	640x360	70	30	5.2
  	CVMS1.2	1.25	600x337.5	480x270	70	30	5.2
  	CVMS1.5	1.5625	600x337.5	384x216	70	30	5.2
  	CVMS1.8	1.875	600x337.5	320x180	70	30	5.2

• Product	Product model	Dot pitch(pixels)	Box dimensions(mm)	Box resolution	Maximum Power Consumption(W)	Average power consumption(W)	Box weight(kg)
  CV MINI Series	CVES0.9	0.9375	600x337.5	640x360	130	60	5
  	CVES1.2	1.25	600x337.5	480x270	110	45	5
  	CVES1.5	1.5625	600x337.5	384x216	105	45	5
  	CVES1.8	1.875	600x337.5	320x180	110	35	5
  	CVES2.5	2.5	600x337.5	240x135	100	35	5

• Product	Product model	Dot pitch(pixels)	Box dimensions(mm)	Box resolution	Maximum Power Consumption(W)	Average power consumption(W)	Box weight(kg)
  CB Series	CB0.9	0.9375	600x337.5	640x360	75	36	4.2
  	CB1.2	1.25	600x337.5	480x270	70	35	4.2
  	CB1.5	1.56	600x337.5	384x216	70	35	4.2

• Product	Product model	Dot pitch(pixels)	Box dimensions(mm)	Box resolution	Maximum Power Consumption(W)	Average power consumption(W)	Box weight(kg)
  U Series	U1.5ES	1.53	640x480	416x312	140	60	7.1
  	U1.8ES	1.86	640x480	344x258	120	45	7.1
  	U2.5ES	2.5	640x480	256x192	130	50	7.1

• Product	Product model	Dot pitch(pixels)	Box dimensions(mm)	Box resolution	Maximum Power Consumption(W)	Average power consumption(W)	Box weight(kg)
  E Series	E2.5i	2.5	960x720	384x288	380	380	19
  	E3i	3	960x720	320x240	380	380	19
  	E4i	4	960x720	240x180	380	380	19
  	E4.8i	4.8	960x720	200x150	380	380	19
  	E6i	6	960x720	160x120	380	380	19
  	E3	3	960x720	320x240	480	480	22
  	E4	4	960x720	240x180	450	450	19.5
  	E5.8	5.8	960x720	164x123	450	450	19.5
  	E8	8	960x720	120x90	500	500	19.5
  	E10	10	960x720	96x72	500	500	19.5

• Product	Product model	Dot pitch(pixels)	Box dimensions(mm)	Box resolution	Maximum Power Consumption(W)	Average power consumption(W)	Box weight(kg)
  EXLF Series	E4LF	4	1152x1728	72x72	1200	360	50
  	E5LF	5.14	1152x1728	56x56	1200	360	50

• Product	Product model	Dot pitch(pixels)	Box dimensions(mm)	Box resolution	Maximum Power Consumption(W)	Average power consumption(W)	Box weight(kg)
  AF Series	AF4	4	960x960	240x240	535	155	24.5
  	AF6	6.67	960x960	144x144	500	166	24.5
  	AF8	8	960x960	120x120	500	155	24.5
  	AF10	10	960x960	96x96	500	166	24.5

• Product	Product model	Dot pitch(pixels)	Box dimensions(mm)	Box resolution	Maximum Power Consumption(W)	Average power consumption(W)	Box weight(kg)
  RM Series	RM1.5	1.56	500x500	320x320	190	95	8.2
  	RM1.9	1.95	500x500	256x256	150	55	8.2
  	RM2.3	2.31	500x500	216x216	167	52	8.2

• Product	Product model	Dot pitch(pixels)	Box dimensions(mm)	Box resolution	Maximum Power Consumption(W)	Average power consumption(W)	Box weight(kg)
  SW Series	SW3.7	3.75	600x1200	160x320	530	158	14
  	SW3.7H	3.75	600x1200	160x160	275	88	8
  	SW5.7	5.76	600x1200	104x208	350	110	110
  	SW5.7H	5.76	600x1200	104x104	170	60	60

• Product	Product model	Dot pitch(pixels)	Box dimensions(mm)	Box resolution	Maximum Power Consumption(W)	Average power consumption(W)	Box weight(kg)
  RMxA Series	SV3.9	3.91	250x250	128x256	380	120	14.8

• Product	Product model	Dot pitch(pixels)	Box dimensions(mm)	Box resolution	Maximum Power Consumption(W)	Average power consumption(W)	Box weight(kg)
  RMxE Series	RM1.5E	1.56	500x500	320x320	190	95	8.2
  	RM2.3E	2.31	500x500	216x216	153	53	8.2

• Product	Product model	Dot pitch(pixels)	Box dimensions(mm)	Box resolution	Maximum Power Consumption(W)	Average power consumption(W)	Box weight(kg)
  RL Series	RL2.3	2.3148	500x1000	216x432	200	220	10
  	RL2.6	2.604	500x1000	192x384	69	80	10

• Product	Product model	Dot pitch(pixels)	Box dimensions(mm)	Box resolution	Maximum Power Consumption(W)	Average power consumption(W)	Box weight(kg)
  RMxC Series	RM1.5C	1.56	500x500	320x320	175	55	9

• Product	Product model	Dot pitch(pixels)	Box dimensions(mm)	Box resolution	Maximum Power Consumption(W)	Average power consumption(W)	Box weight(kg)
  RMxB Series	RM1.5B	1.56	500x500	320x320	185	75	9.3
  	RM2.3B	25.31	500x500	216x216	155	50	9.3

• Product	Product model	Dot pitch(pixels)	Box dimensions(mm)	Box resolution	Maximum Power Consumption(W)	Average power consumption(W)	Box weight(kg)
  C Series	C1.8	1.875	480x480	256x256	110	45	3.88
  	C2.5	2.5	480x480	192x192	100	40	3.88
  	C3	3	480x480	160x160	116	45	3.88

• Product	Product model	Dot pitch(pixels)	Box dimensions(mm)	Box resolution	Maximum Power Consumption(W)	Average power consumption(W)	Box weight(kg)
  SP Series	SP06	6.25	1600x900	256x144	920	290	52
  	SP10	10	1600x900	160x90	1000	290	52

• Product	Product model	Dot pitch(pixels)	Box dimensions(mm)	Box resolution	Maximum Power Consumption(W)	Average power consumption(W)	Box weight(kg)
  SID Series	SID120		2678x1645.5	1920x1080	1300	325	95
  	SID150		3344x2020	1920x1080	1800	400	130
  	SID180		4010x2394.5	1920x1080	2250	570	180
